FJ4DNXC42L00 3.5 Ton Residential Fan Coil Multipoise R-410A (Aluminum Coil)

Description FJ4DNXC42L00 3.5 Ton Residential Fan Coil Multipoise R-410A (Aluminum Coil) – E:Mail: [email protected] to confirm availability or for volume discounts FJ4DNXC42L00 F = Fan Coil / Product J =Type / Tier 4 = Puron® / Refrigerant Type D = Major Series N = 208/230V, 1 ph, 60 Hz / Electrical X = Singular, TXV / Cabinet Type / Metering Device C = 21″ / Cabinet Width 42 = 42,000 / Nominal Capacity L = Aluminum / Coil Type 00 = No Heat / Electric Heater Size The FJ4 fan coil has the proven technology of fan coil units with Puron® refrigerant as well as vertical and horizontal applications. The design features contoured condensate pans with rugged drain connections, ensuring that little water is left in the unit at the end of the cooling duty cycle. The lack of standing condensate and corrosion free pans improves IAQ and product life, features homeowners appreciate. Standard features include grooved tubing and louvered fins. Coil circuiting has also been updated to make the most of all Carrier heat pumps and air conditioners. Units come with solid state fan controls, 1-inch (25mm) thick insulation with R-value of 4.2, multi-speed motors, and fully-wettable coils. Units can accommodate factory- and/or field-installed heaters from 3 to 30 kW. Assembled at the factory compliant with low leak requirements of less than 2% cabinet leakage rate at 0.5 inches W.C. and 1.4% cabinet leakage rate at 0.5 inches W.C. when tested in accordance with ASHRAE 193 standard. The FJ4 fan coil design is loaded with popular features. These fan coils utilize the latest in electronic commutation motor (ECM) technology through the use of high efficiency, multi-tap ECM motors allowing reliable air delivery with increased static pressure. It comes in a pre-painted (taupe metallic) galvanized steel casing and a factory-supplied power plug for ease of installation. The unit is shipped with a Puron refrigerant TXV (sizes 18–60). FEATURES Multi-tap ECM (electronic commutating motor) motors – all sizes Integrated motor controls, with 90-sec off TDR function, have replaced integrated circuit board. Five available speed tags to meet a wide range of applications Large, grooved tube, louvered fin coils Efficient, quiet, time-tested blower housings and diffusers Sturdy, drainable condensate pans Cabinet construction features innovations designed to prevent cabinet sweating. Tested for condensate disposal in much tougher conditions than Air Conditioning and Refrigeration Institute requirements. Super-thick R-4.2 insulation with vapor barrier Pre-painted galvanized steel cabinet (taupe metallic) Design meets stringent regulations for cabinet air leakage of less than 2% when tested at 0.5 inches W.C., and cabinet air leakage less than 1.4% at 0.5 inches W.C. when tested in accordance with ASHRAE 193 standard. Installation-flexible, multipoise units 2-piece modular design available for 42 thru 60 sizes. Facilitates attic and crawlspace installations. Horizontal hanging provisions on cabinet No tools required to access filter. Newly improved filter rack area filter door insulation added for improved air seal. Factory-installed heater packages available on select models (5 through 15 kW). 3 through 30 kW accessory heaters – field installed Factory-supplied power plug Easy plug-in provisions for heater installation. Entry options for high and low voltage wiring hook-up. Leak-preventing sweat connections Thermostatic expansion valve, TXV, on all coils Designed for manufactured housing applications. Attributes Air Flow Direction Multi-Position Approvals UL Listed Blower Motor HP 1/2 Blower Motor RPM 1,050 Blower Motor Speeds 5 (Five) Blower Motor Type ECM (Electronically Commutated Motor) Brand WeatherMaker®, Bryant®, Carrier® CFM 1,225 Cabinet Width 21 Color Taupe Cooling Capacity 39,900-42,000 Cooling Rated Capacity (Btu/h) 42000 Country of Origin USA Cubic Measurement 13.77 Cycle/Hertz 60 Hz Drain Connection Size 3/4″ Energy Star Rated No Filter Size 20″ x 20 Includes Filter Rack Yes Liquid Line Fitting Type Sweat or Braze Liquid Line Size (OD) 3/8″ Maximum Overcurrent Protection (MOCP) 15 Metering Device TXV/TEV – Thermostatic Expansion Valve OPT Code 1PFJ4DNXC42L00 Phase Single Product Family FJ4 Prop 65 Yes Refrigerant R-410A Stage (1) Single Suction Line Fitting Type Sweat or Braze Suction Line Size (OD) 1 1/8″ Tonnage 3.5 UPC See Optical Voltage 208-230 VAC
