ARK RTK GPS L1 L5

Description Dronecan RTK GPS, Magnetometer, Barometer, IMU, Buzzer, and Safety Switch Module Runs PX4 Open Source Firmware Supports Dronecan Firmware Updating Open Source Schematic and BOM Sensors Ublox ZED-F9P-15B GPS L1/L5 Multi-band GNSS receiver delivers centimeter level accuracy in seconds Concurrent reception of GPS, GLONASS, Galileo and BeiDou Multi-band RTK with fast convergence times and reliable performance High update rate for highly dynamic applications Centimeter accuracy in a small and energy efficient module Does not Support Moving Base for Heading Bosch BMM150 Magnetometer Bosch BMP388 Barometer Invensense ICM-42688-P 6-Axis IMU STM32F412CEU6 MCU Safety Button Buzzer Two Pixhawk Standard CAN Connectors 4 Pin JST GH F9P “UART 2” Connector 3 Pin JST GH TX, RX, GND Pixhawk Standard Debug Connector 6 Pin JST SH LED Indicators Safety LED GPS Fix RTK Status RGB System Status USA Built FCC compliant Power Requirements 5V 170mA Average 180mA Max Includes 4 Pin Pixhawk Standard CAN Cable Dual Band (L1/L5) Helical GPS Antenna Documentation 3D Model
